Electrical Specifications

Operating Frequency Band [MHz]

3300-4200/4400-5000

3300-4200/4400-5000

3300-4200/4400-5000

Polarization

±45

±45

±45

Radiation

Directional

Directional

Directional

Gain [dBi]

12.3/13.3

12.96/13.46

12.56/12.84

Electical Downtilt [degrees]

0 (fixed)

0 (fixed)

0 (fixed)

VSWR

≦ 2.0

≦ 2.0

≦ 2.0

Dimension
(Length x width x depth)

160x160x35mm

190x190x40mm

220x220x45mm

Features

1. Low profile, Wideband Operation for small cells

2. X-polarised 2x2 MIMO Antenna for CBRS Band and C-Band 3400-5000MHz

1. Wideband Operation for small cells

2. X-polarised 2x2 MIMO Antenna for CBRS Band and C-Band 3400-5000MHz

1. Wideband Operation for small cells

2. X-polarised 4x4 MIMO Antenna for CBRS Band and C-Band 3400-5000MHz
